Item | D45 |
Power(optional) | 48V5KW(Lead acid/Lithium) |
Chassis frame | High strength sheet metal rectangular frame (electrophoresis + highlight) |
Outline dimension | 2900*1270*2000mm |
Front / rear tread | Front 945mm/Rear 1065mm |
Wheel Axle distance | 2080mm |
Ground clearance | 170mm |
Minimum turning radius | 3.5m |
Net weight | 480kg |
Maximum driving speed | 36.8km/h(Can be adjusted according to customer needs) |
Climbing capacity | 20%-45% |
Standing slope performance | 20% |
Endurance | 96-128km (flat road) |
Braking distance | <3.5m |
Motor voltage(Alternating current) | 48V5KW |
Motor brand | KDS Motor |
Electric control brand | Borcart 48V350A |
Battery | Shengyang lead acid without maintenance 6*8V150AH |
DC converter | High power non isolated DC-DC 48V/12V-300W |
Battery charger | Preston intelligent vehicle charger 48V/25A,charging time < 8 hours (discharge rate 80%) |
Steering system | Bidirectional rack and pinion steering system with automatic clearance compensation function |
Braking system | Zero crossing rear axle: four wheel hydraulic pressure brake, four wheel disc brake + electronic brake parking |
Front suspension | Double swing arm and independent front suspension + coil spring + barrel hydraulic pressure shock absorber. |
Rear suspension | Integral rear axle, speed ratio 16:1,coil spring damping + barrel hydraulic pressure damping + rear stabilizer bar |
Tire specification | DOT certification; Road tire 215/35-14 (4 Ply Rated)//tire |
Ceiling | Frosted black square pipe frame + PP injection molding ceiling |
Floor | PVC Plastic flooring floor, ageing resistance . |
Body of car | The front cover, seat barrel, body and rear cover are molded by special injection material for automobiles; |
Seat | Integral foam forming cushion;High grade imported leather (optional) color separation;Reverse row seat can be turned over,including storage box |
Instrument panel | Injection molding instrument panel, electric lock switch, double arm combination switch, gear switch, electronic hand brake switch, water cup holder; Dual USB data interface, 12V power supply, USB + type-C fast charging. The LCD electric vehicle combination instrument (including fault diagnosis information display) platform is an embedded multimedia touch LCD screen. Optional reverse image. |
Rearview mirror | Adjustable,foldable side rear view mirror ; wide angle mid-rear mirror |
Lights and warning signals | Front combined lamps --dipped lights,high beams,turn lights,day time running light,position lamp,through light/Rear front combined lamps(brake light,position lamp,turn lights) , back up alarm buzzer |
Front windshield and wiper | DOT certified acrylic plexiglass;Optional tempered glass + wiper |
|
Function
1.HASDA IP66 waterproof advanced multimedia combination LCD screen with vehicle status information.
2.HASDA IP66 Full range hi fi speaker H058.
3.First class seats (overall foam seat cushion+solid high-grade imported leather).
4.High strength aluminum alloy oxidation anti-skid floor, corrosion resistance and aging resistance.
|
Suspension and braking system
1. Front suspension: double arm independent front suspension+spiral spring+cylindrical hydraulic shock absorption.
2. Rear suspension: integral rear axle,speed ratio 16:1,coil spring damping+cylindrical hydraulic damping+rear stabilizer bar.
3. Brake system:zero crossing rear axle:four-wheel hydraulic brake,four-wheel disc brake+electronic brake parking.
4. Steering system:two-way rack and pinion steering system,automatic clearance compensation function.
5. Frame: high-strength sheet metal trapezoidal frame (electrophoresis+highlight).
|
CART DETAILS
|
