| Color: | |
|---|---|
| Quantity: | |
Item | D14A | |
Power(optional) | 48V5KW(Lead acid) | 72V5KW(Lithium battery) |
Chassis frame | High strength sheet metal rectangular frame (electrophoresis + highlight) | |
Outline dimension | 4985x1510x2120mm | |
Front / rear tread | Front 1300 mm/Rear 1300 mm | |
Wheel Axle distance | 2770mm | |
Ground clearance | 140mm | |
Minimum turning radius | 6.5m | |
Net weight | 1230kg | |
Maximum driving speed | 30km/h(Can be adjusted according to customer needs) | |
Climbing capacity | 15% | |
Standing slope performance | 15% | |
Endurance | 90km (flat road) | |
Braking distance | <6m | |
Motor voltage(Alternating current) | 48V5KW | 72V5KW |
Motor brand | China brand | |
Electric control brand | Borcart 48V350A | Borcart 72V450A |
Battery | Shengyang lead acid without maintenance 6*8V150AH | Guosheng 72v120ah lithium iron phosphate |
DC converter | High power non isolated DC-DC 48V/12V-300W | High power non isolated DC-DC 72V/12V-300W |
Battery charger | Preston intelligent vehicle charger 48V/25A,charging time < 8 hours (discharge rate 80%) | Standard lithium iron phosphate charger |
Steering system | Double-pinion gear rack steering + electric speed-dependent steering assist system (with active correction) | |
Braking system | Front ventilated disc rear drum hydraulic dual-circuit braking + handbrake parking, with vacuum-assisted braking system | |
Front suspension | Front axle McPherson independent suspension, with coil springs and tube-type hydraulic shock absorbers | |
Rear suspension | Integral rear axle, coil springs + tubular hydraulic shock absorber | |
Tire specification | Vacuum equatorial tire 195/70R15, steel wheel rim with wheel rim cover | |
Ceiling | Enhanced composite material skin + aluminum alloy frame + sheet metal front windshield; featuring light weight, anti-aging properties, and resistance to fading. | |
Floor | Aluminum alloy patterned floor, non-corrosive, sturdy, durable and beautiful | |
Seat | PU automotive-specific seats, in line with ergonomic principles | |
Rearview mirror | Adjustable,foldable rear view mirror | |
Lights and warning signals | LED high/low beam headlights, turn signals, rear combination taillights, horn, reversing buzzer | |
Front windshield | Automotive-grade laminated glass+With glass washer and dual swing-arm wipers | |
|
Suspension and braking system
1. Front suspension: double arm independent front suspension+spiral spring+cylindrical hydraulic shock absorption.
2. Rear suspension: integral rear axle,speed ratio 16:1,coil spring damping+cylindrical hydraulic damping+rear stabilizer bar.
3. Brake system:zero crossing rear axle:four-wheel hydraulic brake,four-wheel disc brake+electronic brake parking.
4. Steering system:two-way rack and pinion steering system,automatic clearance compensation function.
5. Frame: high-strength sheet metal trapezoidal frame (electrophoresis+highlight).
|
